by David Crane
defrev at gmail dot com

All photographic images contained in this article were taken by
DefenseReview.com, and they are the exclusive property of
DefenseReview.com. DefenseReview.com owns the copyright on these
photos. All photos were shot with a 7.2-megapixel Sony Cyber-shot
digital camera (Model #: DSC-P150).

February 21, 2008

Ashbury International Group Inc. (AIG) had an interesting .338 Lapua Magnum modular sniper rifle / anti-materiel rifle a.k.a. modular long-range-interdiction rifle at their booth at SHOT Show 2008 called the Asymmetric Warrior ASW338LM Precision Sniper Rifle (PSR) (MOD-1A2) that was built using their Folding Rifle Stock System Tactical SABER-FORSST Modular Stock Chassis System (MSCS) with unitized monolithic Mil-Std-1913 "Picatinny" rail (0-thru-60MOA) and Surgeon XL Action (SXL-A2) bolt action with integrated 30MOA Picatinny scope rail, and was designed and developed to allow a sniper to engage and neutralize enemy personnel and "lightly armored threats" at ranges of up to 1500 yards during day and night, and in the near-infrared (night vision) and true infrared (IR) / thermal spectrums.

The ASW338LM PSR bolt-action rifle immediately reminded us of the…

AshburySaberSXL A2 FoldingRifleStockSystemTactical 1 small SHOT Show 2008 2 03 08 <!  :en  >AIG Asymmetric Warrior ASW338LM .338 Lapua Magnum Modular Precision Sniper Rifle<!  :  >
PGM Precision family of modular anti-materiel and sniper rifles (PGM Ultima Ratio Intervention, Commando I, and Commando II, Hecate II, Mini Hecate, and PGM 338 LM) and the Advanced Military System Design (AMSD) OM 50 Nemesis .50 BMG Sniper Rifle System modular anti-materiel/sniper rifle.

DefenseReview’s time at each company’s booth was very limited, so we didn’t get to spend as much time at the Ashbury booth as we would have liked, nor did we get to talk with the Ashbury representatives as much as we would have liked. However, Morris Peterson, Ashbury’s President & CEO, and Richard Hall, Ashbury’s Vice President of Business Development, were both very personable and enthusiastic, and assisted us as much as they could in the short time we were at the AIG booth.

While we were there, we picked up an interesting piece of literature on the Ashbury International Group Rapid Product Development Center (RPDC) (part of the Engineering Services Group) which can rapidly fabricate 3D (3-D) physical objects directly from CAD data sources using Solidworks and Pro-E CAD software. Basically, it’s a state-of-the-art rapid-prototyping facility.

AshburySaberSXL A2 FoldingRifleStockSystemTactical 3 small SHOT Show 2008 2 03 08 <!  :en  >AIG Asymmetric Warrior ASW338LM .338 Lapua Magnum Modular Precision Sniper Rifle<!  :  >
Asymmetric Warrior ASW338LM Precision Sniper Rifle Specs and Features:

The Asymmetric Warrior ASW338LM MOD-1A2 PSR is bolt-action and features a 10-round detachable box magazine (CIP length). It is, according to the company, capable of sub-1MOA (i.e. sub-1 Minute-Of-Angle) accuracy with selected ammo. Chamber is hybrid CIP Spec .338LM. Barrel is 416 stainless steel 5R, has a "ballistically-engineered barrel contour", and is available in 20" or 27" lengths. The rifle incorporates an integrated heat/mirage shield and suppressor cover, and utilizes a Surefire muzzle brake and sound suppressor. The weapon’s trigger is a Remington X-Mark Pro adjustable trigger. Tactical Scope options are Leupold, Nightforce, or Schmidt & Bender. The weapon’s pistol grip is a MagPul MIAD Grip (MIssion ADaptable Grip).

According to company literature, the PSR features mil-spec anti-corrosion and hard surface coatings. Included in the package is 2500 rounds of RUAG .338 Lapua Magnum (.338LM) ammo, including AP (Armor Piercing a.k.a. Armor Penetrating), ball, match, tactical (for engaging targets behind glass), and STYX Action high-impact deformation rounds.

Included in the package is a "field operations load out kit / deployment transit case for transporting the rifle, various accessories and ammo.

The basic rifle weighs 17 lbs.

There are some upgrade options available to assist in fulfilling end-user and mission-specific requirements, including an ASW338LM Sniper Equipment Suite, Modular Universal Sniper Accessory System (MUSAS) and various user-configurable modifications.

Ashbury Thermal Sight Laser Pointer Illuminator 1 <!  :en  >AIG Asymmetric Warrior ASW338LM .338 Lapua Magnum Modular Precision Sniper Rifle<!  :  >
Folding Rifle Stock System Tactical (FRSST) SABER-FORSST Modular Stock Chassis System (MSCS) Specs and Features:

The Ashbury FRSST SABER-FORSST MSCS is designed to be highly ergonomic and constructed primarily from high-strength aerospace-grade aluminum alloy. It should be noted that the heatshield (a.k.a. heat shield) appears to be made from carbon fiber. The system features a precision bedding-less action interface, and accepts both 5-round and 10-round detachable box mags. The folding buttstock is available in both right and left-hand config, and is retractable/telescoping and fully adjustable. The standard forend railtube is a quad rail or "Quattro", but additional interchangeable forend rail tube designs are available.

The Ashbury modular stock chassis system can be used to "enhance existing bolt-action rifle platforms" like the M40A3 (Rem700 S/A) and M24 Sniper Weapon System (SWS) (Rem700 L/A) rifles.

The system sports the aforementioned mil-spec corrosion protection and hard surface coating. Weight is approx. 6.5 lbs. Available colors are Dark Earth, Gray, Black and O.D. Green.

System Advantages:

The Ashbury technical data sheet on the Modular Stock Chassis System and Asymmetric Warrior ASW338LM Precision Sniper Rifle (PSR) highlights the following "system advantages":

1) Use of four (4) different bipod systems: Versapod, Parker Hale, Harris and X-Caliber

2) Electro-Optic and Active Laser System Compatibility:

- STORM/RULR (Laser Range Finders)
- Insight Technology ATPIAL (Advanced Target Pointer Illuminator Aiming Light) and AN/PEQ-2A Target Pointer, Illuminator, Aiming Light, (TPIAL) (Laser Sights/Illuminators)
- Remote Video Display
- Night Vision Weapon Sights: IWNS, AN/PVS-22, AN PVS-26 and AN/PVS-27
- Thermal Weapon Sights: UNS-T and UNS-T/LR


Advanced Camouflage Technology Initiative (ACTI):

Defense Review also got some literature on AIG’s ACTI Over-Garment Suite, which was designed and developed under the Advanced Camouflage Technology Initiative (ACTI) in order to provide military and law enforcement personnel with "environmentally specific camouflage patterns; scientifically, behaviorally, and geometrically designed to enhance visual deception [and, most likely, visual disruption] for personnel, shelters, weapons, equipment and tactical vehicles for particular geographic regions."

The following comes from Ashbury’s product literature, the ACTI Over-Garment Suite:

"The ACTI Over-Garment Suite is environmentally texture-matched for global Arid and Semi-Arid regions from low to high elevations. Loose Over-Garments (like military ‘Over-Whites’) help break up the human form, color, shape and shadow. They also provide the user with the flexibility to change camoufalge patterns for different operational areas. The ACTI Over Garment Suite is comprised of a specially-designed smock, bibbed over-pants and pack cover. The garment suite design is an integral part of the toatal concealment approach to modern camouflage.

ACTI is a systematic camouflage technology design for specific environments, terrain and elevations specifically to defeat human visual detection and recognition as there is no universal camouflage!"

The ACTI Over-Garment Suite Features:

- Dual reversible patterns in one over-garment system
- Color palate is geographically specific
- Terrain and elevation matched
- Geometric break-up and human form
- Lightweight breathable materials
- Semi-Disposable
- Mission Configurable
- Augments in-service uniforms


Company Contact Info:

Ashbury International Group, Inc.
Tactical Systems Integration Division
P.O. Box 8024
Charlottesville, VA 22906
434-296-8600 Office
434-296-9260 Fax
[email protected] Email
www.ashburyintlgroup.com Website
